Description
By (author) Razavi Behzad
:
Fundamentals of Microelectronics, 3rd Edition, is a comprehensive introduction to the design and analysis of electrical circuits, enabling students to develop the practical skills and engineering intuition necessary to succeed in their future careers. Through an innovative “analysis by inspection” framework, students learn to deconstruct complex problems into familiar components and reach solutions using basic principles. A step-by-step synthesis approach to microelectronics demonstrates the role of each device in a circuit while helping students build “design-oriented” mindsets.
The revised third edition covers basic semiconductor physics, diode models and circuits, bipolar transistors and amplifiers, oscillators, frequency response, and more. In-depth chapters feature illustrative examples and numerous problems of varying levels of difficulty, including design problems that challenge students to select the bias and component values to satisfy particular requirements. The text contains a wealth of pedagogical tools, such as application sidebars, chapter summaries, self-tests with answers, and Multisim and SPICE software simulation problems. Now available in enhanced ePub format, Fundamentals of Microelectronics is ideal for single- and two-semester courses in the subject.
Table of contents:
1 Introduction To Microelectronics 1
1.1 Electronics Versus Microelectronics 1
1.2 Examples of Electronic Systems 2
1.2.1 Cellular Telephone 2
1.2.2 Digital Camera 5
1.2.3 Analog Versus Digital 7
1.3 Basic Concepts 8
1.3.1 Analog and Digital Signals 8
1.3.2 Analog Circuits 10
1.3.3 Digital Circuits 11
1.3.4 Basic Circuit Theorems 12
1.4 Chapter Summary 20
2 Basic Physics Of Semiconductors 21
2.1 Semiconductor Materials and Their Properties 22
2.1.1 Charge Carriers in Solids 22
2.1.2 Modification of Carrier Densities 25
2.1.3 Transport of Carriers 28
2.2 pn Junction 35
2.2.1 pn Junction in Equilibrium 36
2.2.2 pn Junction Under Reverse Bias 41
2.2.3 pn Junction Under Forward Bias 46
2.2.4 I/V Characteristics 49
2.3 Reverse Breakdown 54
2.3.1 Zener Breakdown 55
2.3.2 Avalanche Breakdown 55
2.4 Chapter Summary 56
Problems 57
SPICE Problems 60
3 Diode Models and Circuits 61
3.1 Ideal Diode 62
3.1.1 Initial Thoughts 62
3.1.2 Ideal Diode 63
3.1.3 Application Examples 67
3.2 pn Junction as a Diode 72
3.3 Additional Examples 74
3.4 Large-Signal and Small-Signal Operation 80
3.5 Applications of Diodes 89
3.5.1 Half-Wave and Full-Wave Rectifiers 89
3.5.2 Voltage Regulation 100
3.5.3 Limiting Circuits 103
3.5.4 Voltage Doublers 106
3.5.5 Diodes as Level Shifters and Switches 112
3.6 Chapter Summary 114
Problems 115
SPICE Problems 122
4 Physics of Bipolar Transistors 124
4.1 General Considerations 125
4.2 Structure of Bipolar Transistor 126
4.3 Operation of Bipolar Transistor in Active Mode 127
4.3.1 Collector Current 129
4.3.2 Base and Emitter Currents 133
4.4 Bipolar Transistor Models and Characteristics 135
4.4.1 Large-Signal Model 135
4.4.2 I/V Characteristics 137
4.4.3 Concept of Transconductance 139
4.4.4 Small-Signal Model 141
4.4.5 Early Effect 145
4.5 Operation of Bipolar Transistor in Saturation Mode 152
4.6 The PNP Transistor 155
4.6.1 Structure and Operation 155
4.6.2 Large-Signal Model 156
4.6.3 Small-Signal Model 159
4.7 Chapter Summary 162
Problems 163
SPICE Problems 170
5 Bipolar Amplifiers 172
5.1 General Considerations 173
